D3-010
Titan power in a compact 8U console
- Standalone Titan console with integrated processing, no laptop required
- Supports 8 DMX universes natively
- 10 playback faders, 3 encoder wheels, 12 macro buttons and features Avolites’ Compact key layout
- Compatible with USB-C touchscreen
Access powerful Titan control in our smallest ever portable console.
Powered by Titan, D3-010 supports 8 universes without a laptop: just add a monitor and you’re ready to go. Built for live environments, D3-010 is compact, tough, travel-ready, and performs straight out of the case.
Avolites Titan & Capture Engine
8 Universes (4,096 channels)
Unlimited Fixtures
TitanNet Multi-Console session
Streaming ACN
Art-Net & Art-RDM
CITP
SMPTE LTC
Downloads
| Name | Description | Last Modified | Size | Download |
|---|---|---|---|---|
| NameD3-010 datasheet (v1) | Description | Last Modified | Size | Download Download |
Technical Spec
1x up to 4K (UHD) external screen (USB-C or DisplayPort)
Compact layout (reduced version of D7 & D9 layouts)
10x 60mm playback faders
20x C&K flash buttons with custom cap
76x backlit Cherry MX Low Profile programming / setup keys
3x backlit Cherry MX Low Profile playback paging keys
5x backlit Cherry MX Low Profile playback control keys, incl. double-width Go key
12x backlit Cherry MX Low Profile macro/executor keys
3x high resolution, metal Avo attribute encoders with select buttons
Support for D3 Wing, T3 Wing, or Titan Mobile Wing
Support for unlimited D3 Touch
iOS & Android mobile app ("Titan Remote")
4x DMX ports (Neutrik 5-pin XLR)
2x RJ45 (Gigabit Ethernet)
1x SMPTE LTC port (Neutrik 3-pin XLR)
Weights and Dimensions
DIMENSIONS (W x D x H): 398 x 275 x 78 mm
WEIGHT: 4.6 kg
PACKAGED DIMENSIONS (W x D x H): 575 x 343 x 149 mm
PACKAGED WEIGHT: TBC
PACKAGING: Cardboard
